CHERY B113724031 WIRING HARNESS

CHERY B113724031 WIRING HARNESS

Product Specifications

Product quality
OEM Equivalent Grade
starstarstar
Wholesale price USD $2.13
Wholesale price CNY ¥14.4
bolt MOQ (Minimal order)
1 pcs
local_shipping Production time
30-45 days
package_2 Shipping Weight: —
add_shopping_cart BUY NOW
CHERY B113724031
Overview & Operating Principle
▲

The WIRING HARNESS is an automotive wiring harness assembly — a precisely engineered bundle of insulated copper conductors, shielded data cables, connector housings, and protective conduit that forms the complete electrical interconnection infrastructure for a specific vehicle system or zone, routing power, ground, and signal circuits between control modules, sensors, actuators, and junction boxes in a single pre-terminated, routing-specific assembly that installs as one unit. Unlike individual wires routed separately, a wiring harness integrates all conductors for a functional group — engine management, transmission control, instrument cluster, door, or body — into a single routed assembly whose branching topology, conductor gauges, connector pinouts, and protective sleeve selection are engineered simultaneously for the electromagnetic compatibility, current-carrying capacity, and service environment requirements of the specific vehicle architecture. Each conductor's cross-sectional area is selected for the maximum sustained current of its circuit plus a safety margin; shielded twisted pairs carry differential CAN bus, LIN bus, and analogue sensor signals where electromagnetic interference immunity is critical; high-current circuits for starter motors, alternators, and heating elements use heavy-gauge unshielded conductors with appropriately rated connectors; the complete harness is wrapped in corrugated conduit, braided sleeve, or foam tape at positions where abrasion, heat, or moisture resistance is required. The connector housings at each harness end use application-specific terminal types — male or female, sealed or unsealed, locking or friction-fit — selected for the mating connector on the component being connected, ensuring correct polarity and preventing accidental mis-connection of adjacent identical connectors through colour coding, terminal count, or housing shape differentiation.

This unit — CHERY B113724031 — is manufactured to OEM-equivalent specifications: conductor gauge, insulation material and temperature rating for each circuit, connector housing type and terminal material for each connection point, overall harness routing length and branch positions, shielding specification for data signal conductors, protective sleeve type and position, and circuit count and pinout assignment are matched to the original part. Supplied as a complete pre-terminated harness assembly ready for installation. Available wholesale from 2.13 USD, MOQ 1 pcs, production lead time 30-45 days.

Wiring harnesses fail through insulation chafing where the harness contacts a sharp body edge, a hot surface, or a moving component — the insulation wears through and the bare conductor contacts the body, creating a short circuit that blows a fuse or damages the connected module; through connector terminal corrosion from moisture ingress at unsealed connectors in underbonnet or underbody positions that increases contact resistance, producing voltage drop faults and intermittent component operation; through conductor fatigue fracture at repeated flex points — typically at door-to-pillar transition grommets where the harness flexes thousands of times during normal vehicle use — producing an intermittent open circuit that is extremely difficult to locate without harness replacement; and through rodent damage where insulation is stripped from conductors over a significant harness length, typically in vehicles stored for extended periods.

Symptoms & Diagnostics
▲
Multiple fault codes across several systems stored simultaneously — codes for sensors, actuators, and modules that are not functionally related to each other — appearing after a single event such as a short circuit, rodent damage, or water ingress — a single harness fault that affects the power or ground supply to multiple components simultaneously produces unrelated-appearing fault codes across all affected systems; the common factor — shared supply voltage, shared ground, or shared harness routing — identifies the harness as the fault source rather than multiple simultaneous component failures.
Intermittent fault codes — faults that appear and disappear unpredictably without correlation to temperature, engine load, or driving conditions — on one or more circuits routed through the same harness section — conductor fatigue fracture at a flex point produces an intermittent open circuit that makes contact under some physical positions and loses contact under others; the intermittent nature makes the fault extremely difficult to reproduce during a workshop inspection; wiggling the harness section while monitoring the affected circuit with a scan tool live data view reveals the fault location.
Blown fuse that recurs immediately after replacement — the replacement fuse blows within seconds or minutes of installation — a short circuit in the harness is drawing above the fuse's rated current; locate the short by disconnecting one connector at a time while monitoring the circuit resistance — the section that shows zero ohms to ground when disconnected contains the short; do not install a higher-rated fuse to bypass the repeated blowing — the fuse protects the harness from fire and must be the correct rating.
System fault that is position-sensitive — the affected component or system works when the harness is in one physical position and fails when the harness moves — such as a door module that works with the door open but fails with the door closed — conductor fracture at the door-to-pillar flex grommet is the classic presentation; the conductor makes contact when the flex grommet is at rest position and opens when the door closes and the grommet flexes; confirm by temporarily holding the harness in the fault-free position and confirming the fault does not appear.
Burning smell from the engine bay or passenger compartment — combined with a blown fuse or circuit that will not power up — a short circuit has caused the harness insulation to overheat before the fuse blew; inspect the harness routing visually for discoloured, melted, or charred insulation; a harness with heat damage at any point requires complete replacement — locally repaired harnesses with spliced conductors are not acceptable for high-current circuits where the splice's increased resistance generates heat under sustained current.
Visible damage to the harness exterior — chafed insulation, exposed copper conductors, corroded connector terminals, or missing conduit sections — identified during underbonnet or underbody inspection — any visible insulation breach in a vehicle harness is a fire and reliability risk; even a conductor that is not currently shorting to the body will short under the mechanical stress of engine movement, vibration, and thermal cycling; replace the complete harness assembly rather than attempting an insulation tape repair on a safety-relevant automotive circuit.
