TOYOTA/LEXUS 7539235200 CLIP
Product Specifications
Product quality
OEM Equivalent Grade
Wholesale price USD
$0.03
Wholesale price CNY
¥0.18
bolt MOQ (Minimal order)
1 pcs
local_shipping Production time
20-50 days
package_2 Shipping Weight:
—
swap_horiz
Application (cross references) 3
expand_more
| TOYOTA/LEXUS | 7539235200 |
| TOYOTA/LEXUS | 7539204010 |
| TOYOTA/LEXUS | 753920R010 |
Overview & Operating Principle
▲
The CLIP is an injection-moulded plastic fastener that secures trim panels, body cladding, underbody shields, wheel arch liners, bumper fascias, interior door cards, headlining panels, and wiring harness routing clips to sheet metal bodywork or structural substrates without the use of threaded fasteners, providing a vibration-resistant, rattle-free connection that can be released and reinstalled a defined number of times before the retaining legs fatigue and require replacement. The clip body is typically moulded from polyamide (nylon), polypropylene, or acetal resin, selected for the specific combination of flexibility, impact resistance, and temperature range required for the installation location — underbody and engine bay clips use glass-filled nylon for high temperature and chemical resistance; interior trim clips use unfilled polypropylene for softer engagement feel and lower panel removal force; body panel clips use acetal for consistent retention force across temperature cycles. Retention is achieved through one of several locking mechanisms: push-in expanding anchors whose legs splay outward when the clip pin is driven home; quarter-turn bayonet fasteners that lock with a 90-degree rotation; barbed tree clips for wiring harness routing; and snap-fit C-clips for edge-mounted panel retention.
This unit — TOYOTA/LEXUS 7539235200 — is manufactured to OEM-equivalent specifications: clip body flange outer diameter, pin diameter and expansion leg geometry, panel hole diameter and sheet metal thickness range, retention force and pull-out force, temperature rating, and material compound are matched to the original part. Supplied as a direct replacement for standard fitment. Available wholesale from 0.03 USD, MOQ 1 pcs, production lead time 20-50 days.
Plastic clips are single-use or limited-use fasteners that break during panel removal when the expansion legs are overstressed beyond their elastic limit — which occurs on every removal if the clips are old and UV-embrittled, and frequently on first removal if a clip removal tool is not used. Broken clips left in panel holes prevent the panel from seating flush, create rattles from the loose panel, and allow water ingress into door cavities through unseated clips. Always have a full set of replacement clips available before removing any trim panel; ordering after the fact extends the repair time and leaves the panel temporarily unsecured.
Symptoms & Diagnostics
▲
Trim panel rattle over road undulations or rough surfaces that cannot be eliminated by pressing on the panel from outside — one or more clips have fractured and the panel is loose at those positions; press on the panel face directly over each clip hole position and note whether the rattle changes character — a rattle that reduces when the panel is pressed confirms a missing or broken clip at that location.
Trim panel that does not sit flush with the adjacent body surface — one edge standing proud or one corner recessed — a broken clip on the proud edge is not retaining that section of the panel against the body; the panel has flexed to the unretained position and cannot be pushed flush without a new clip engaging in the sheet metal hole.
Water leak into the door cavity or boot area after rain or a car wash — water dripping from the door sill or appearing on the interior carpet — missing door membrane clips or body seal clips are allowing water that enters the door cavity to bypass the drainage path and overflow into the passenger compartment; inspect the door membrane clip perimeter for broken or missing clips at the water entry point.
Wheel arch liner contact with the tyre at full lock or over bumps — a liner that has dropped partly out of its clip positions is no longer held in its designed clearance position relative to the tyre; a liner in contact with the tyre will be abraded through within a short distance and the debris it generates can jam in the steering or contaminate the brake disc.
Wind noise from a specific door or window surround area at motorway speed — a trim seal or door surround panel clip has failed, allowing the seal to lift partially from the body at speed; the gap between the lifted seal and the body creates a turbulent airflow path that produces a specific tonal wind noise that localises to the affected clip position.
Panel clips visible in the door cavity floor or in the underbody inspection tray after a service or panel removal — broken clips that fell out during the previous repair were not replaced; count the clip holes in the reinstalled panel and compare against the number of clips engaged; any unoccupied clip hole requires a new clip to restore full panel retention and sealing.
Logistics & Customs
▲
International HS Code
3926.30
EAEU Customs Code (TN VED)
3926 30 000 0
Typical Net Weight
Country of Manufacture
China
Standard MOQ
1 pcs
Production Lead Time
20-50 days
Always verify the exact 8-digit or 10-digit subheading with your customs broker for the destination country, as tariff schedules and duty rates vary by jurisdiction.
Installation Tips
▲
- Use a dedicated plastic trim removal tool to release clips during panel removal — a flat-blade screwdriver or metal pry bar concentrates removal force on one leg of the clip, overstressing and fracturing it; a trim removal tool applies distributed force across the full clip flange, releasing the panel from the clip body without fracturing the expansion legs; on panels where the clips are visible from behind, push the pin back to collapse the legs before withdrawing the clip from the hole.
- Remove any broken clip bodies from sheet metal holes before installing new clips — a broken clip body jammed in the hole prevents the new clip from seating to its correct depth; use long-nose pliers or a reverse-thread extractor to withdraw the broken body; if the sheet metal hole has been deformed by a clip that was levered out rather than released, use a round file to restore the hole to its correct diameter before fitting the new clip.
- Confirm the new clip's panel hole diameter and sheet metal thickness range matches the application before bulk installation — clips that are nominally the same size but rated for a different panel thickness or hole diameter will either not engage fully or will engage but provide insufficient retention force; always verify the clip specification against the panel and sheet metal dimensions at the installation location.
- Press each clip fully home until the retention click is felt or heard — a partially engaged clip that appears flush may not have fully expanded its retaining legs; apply firm thumb pressure centred on the clip pin until the legs fully engage with the sheet metal; on two-piece expanding clips (separate pin and body), press the body into the hole first, then drive the pin home until flush with the body flange.
- On underbody shields and wheel arch liners, replace all clips in the panel simultaneously rather than only the broken ones — UV exposure and thermal cycling at underbody temperatures embrittle all clips uniformly; a liner retained by a mix of new and old embrittled clips will lose the old clips at the next removal or road impact, requiring another full set replacement within a short interval.
- Install the new CLIP (TOYOTA/LEXUS 7539235200) in all panel positions, refit the panel by pressing firmly at each clip location until all retention clicks are confirmed, check the panel perimeter for flush fit and even gap to adjacent panels, test for rattle by pressing and releasing the panel face at each clip position, and confirm no wind noise at the affected area during a short road test before returning the vehicle to service.
Tools: plastic trim removal tool set, long-nose pliers for broken clip extraction, round file for deformed hole restoration, rubber mallet for panel seating on stiff clips.
Frequently Asked Questions
▲
How many clips should be ordered when replacing clips on a specific panel?
Order the full count of clips used in the panel plus a 20–30% surplus for every panel removal job. The OEM parts catalogue lists the exact clip count for each panel position by part number; alternatively, count the clip holes in the removed panel before ordering. On high-mileage vehicles where clips have become UV-embrittled, plan to replace every clip in the panel simultaneously rather than only the broken ones — a mixed population of new and old embrittled clips means the old ones will break at the next removal, requiring a repeat clip order. ok.parts supplies clips individually and in workshop packs at wholesale MOQ from 0.03 USD per unit, making complete-set replacement economical for fleet and workshop stocking.
Can a universal clip be substituted when the OEM clip is not available, and what dimensions need to match?
Universal clips can substitute for OEM clips provided four dimensions match: the panel hole diameter (typically 6, 8, 10, or 12 mm on most vehicles), the sheet metal thickness range the clip is designed for, the flange outer diameter that determines how much of the panel hole the clip covers, and the panel thickness the clip bridges between its flange and its retention point. The clip material must also be appropriate for the installation temperature — standard polypropylene clips are not suitable for underbody or engine bay positions that exceed 100°C. Always verify all four dimensions against the removed clip or the panel hole specification before fitting universal replacements.
How does the OEM-equivalent aftermarket unit compare to the genuine OEM part?
OEM-equivalent units in this catalogue replicate the current OEM design geometry and material specification. Quality is verified against OEM cross-reference data. When ordering in bulk, confirm with our team that the specification matches the latest OEM revision for your application.
Is white-label or custom packaging available for wholesale orders?
Yes. ok.parts works directly with the manufacturing facility and can accommodate neutral white-label packaging or fully branded packaging with your company logo, part numbers, and barcode. Minimum order quantities and lead times for custom packaging may differ from standard stock. Contact the team via the inquiry form to discuss your specific requirements.
Frequently Replaced Together
▲
| Part | Reason for Combined Replacement |
|---|---|
| Wheel Arch Liner Front or rear, OEM ref. varies by body position | A wheel arch liner that has been retained by broken or missing clips for an extended period will have flexed repeatedly under wheel rotation airflow, developing stress cracks at the clip hole perimeters. A liner with cracked clip holes cannot retain new clips reliably as the hole perimeter material is too weak to resist the clip's retention load. If the liner shows crack damage at multiple clip positions, replace the liner and all clips simultaneously rather than fitting new clips into a structurally compromised liner. |
| Underbody Shield / Engine Undertray OEM ref. varies by engine bay layout | An underbody shield that has been dragging on the road due to missing clips will have sustained impact and abrasion damage to its underside surface. If the shield has been dragging, inspect it for deformation, stress cracking at clip holes, or material loss from road contact before refitting with new clips — a damaged shield provides less aerodynamic, thermal, and stone chip protection than the OEM design and may warrant replacement alongside the new clip set. |
| Door Membrane / Vapour Barrier Application-specific adhesive or clip-retained sheet | The door membrane that seals the inner door cavity from the passenger compartment is retained by clip-type fasteners along its perimeter on clip-retained designs. A membrane with missing or broken perimeter clips allows door cavity water to flow past the membrane into the door card cavity and passenger compartment. Inspect the full membrane perimeter clip count whenever a door card is removed and replace all clips simultaneously to restore the membrane's waterproof sealing function. |
