TOYOTA/LEXUS 5344069075 WIPER ARM

TOYOTA/LEXUS 5344069075 WIPER ARM

Product Specifications

Product quality
OEM Equivalent Grade
starstarstar
On request
bolt MOQ (Minimal order)
1 pcs
local_shipping Production time
30-45 days
package_2 Shipping Weight: —
add_shopping_cart BUY NOW
TOYOTA/LEXUS 5344069075
TOYOTA/LEXUS 5345039225
TOYOTA/LEXUS 5345069065
TOYOTA/LEXUS 5344069055
TOYOTA/LEXUS 5345069055
LYNXAUTO GS1006
Overview & Operating Principle
▲

The WIPER ARM is the wiper arm — the spring-loaded pivoting lever that connects the wiper motor output shaft or linkage pivot spindle to the wiper blade — that presses the blade against the windscreen surface with the designed contact force throughout the full swept arc and transmits the motor's oscillating drive motion to the blade at the correct geometry for the windscreen's curvature. The arm body is a pressed or cast steel or aluminium lever with a tapered splined bore at its pivot end that locks onto the wiper motor output spindle or the wiper linkage pivot post via an interference fit secured by a retaining nut; a pivot joint near the spindle end allows the blade carrier section to articulate away from the screen for blade replacement and to accommodate the windscreen's local curvature across the sweep arc; and a coil torsion spring integrated into the pivot joint or the arm body provides the constant contact force — typically 100–200g at the blade midpoint — that presses the blade rubber against the glass. The arm's geometry — its effective length, pivot-to-blade tip distance, and the angle at which it meets the screen — is precisely designed for the specific vehicle's windscreen curvature and the wiper motor linkage geometry to ensure the blade sweeps the maximum required area while maintaining the correct attack angle of the blade edge against the glass throughout the sweep.

This unit — TOYOTA/LEXUS 5344069075 — is manufactured to OEM-equivalent specifications: splined bore taper angle and spline count for pivot spindle engagement, arm body length and blade attachment position, torsion spring load and pre-tension for the correct blade contact force, wiper blade attachment type (hook, pin, or bayonet) and blade retention geometry, park position stop geometry, and overall arm mass and balance for the specific wiper motor torque rating are matched to the original part. Supplied as a direct replacement for standard fitment. Available wholesale from 0.18 USD, MOQ 1 pcs, production lead time 30-45 days.

Wiper arms fail through torsion spring fatigue that reduces the blade contact force below the minimum required to maintain glass contact — a spring that has weakened allows the blade to lift from the glass at motorway speeds or to produce an unwiped stripe across the swept arc at the point of lowest contact pressure; through splined bore wear or corrosion that prevents the arm from locking correctly onto the pivot spindle, causing the arm to slip angularly during operation; and through arm body corrosion and fracture at the pivot joint from road salt and age. Spring fatigue is the most common failure mode and is frequently overlooked — a chattering or lifting blade on a vehicle with a new blade and correct washer fluid should always prompt arm spring force testing before the blade is blamed.

Symptoms & Diagnostics
▲
Blade lifting from the windscreen at motorway speeds leaving an unwiped arc at the outer blade tip — aerodynamic lift at high speed is overcoming the spring's contact force; test arm spring pressure by manually lifting the arm away from the screen to its fully raised position and noting the resistance — a fatigued spring feels noticeably lighter than the opposite arm; compare both driver and passenger arms simultaneously; the weaker arm requires replacement regardless of whether the blade itself is new.
Unwiped band across the swept arc at a specific position — typically near the park position or at the outer arc extreme — with a new blade confirmed and washer fluid applied — the spring contact force is insufficient at the point of lowest geometric advantage in the arm's sweep; this contact force variation across the arc is normal to a degree but becomes a wiping deficiency when the spring has weakened; a new blade on a fatigued arm cannot compensate for insufficient spring load.
Wiper arm that has rotated on the pivot spindle — the park position has shifted angularly, leaving the blade resting on the windscreen surround trim or bonnet rather than in the designed park position — the splined bore has slipped on the spindle from corrosion, worn splines, or insufficient retaining nut torque; the wiper motor continues to sweep the arm but from a shifted angular reference, potentially sweeping outside the designed arc and contacting the A-pillar trim.
Wiper arm pivot joint that will not lock in the raised position for blade replacement — the arm falls back to the screen immediately when raised — the pivot joint detent mechanism has failed; replacing the blade with an arm that falls back risks a metal-to-metal contact between the bare arm end and the screen if the blade is removed; a failed detent also causes the arm to apply variable contact force depending on where in the arc the arm is resting, producing irregular wiping quality.
Visible corrosion, cracking, or deformation of the arm body — particularly at the pivot joint or at the blade attachment point — structural damage to the arm body alters the arm's effective geometry, changing the blade's attack angle against the screen across the arc; a deformed arm cannot be straightened reliably — replace it; a corroded arm with surface rust only can be cleaned, painted, and reused if the spring force is confirmed correct.
Wiper blade that chatters across the screen during each sweep despite a new blade and correct washer fluid application — the arm's attack angle — the angle at which the arm meets the screen — has changed from a bent or deformed arm body; an incorrect attack angle prevents the blade rubber from rolling smoothly across the glass and causes it to skip; confirm by checking the arm body for any visible bend compared to the opposite arm's geometry.
Logistics & Customs
▲
International HS Code
8512.90
EAEU Customs Code (TN VED)
8512 90 900 0
Typical Net Weight
Country of Manufacture
China
Standard MOQ
1 pcs
Production Lead Time
30-45 days
Always verify the exact 8-digit or 10-digit subheading with your customs broker for the destination country, as tariff schedules and duty rates vary by jurisdiction.
Installation Tips
▲
  1. Mark the spindle position relative to the arm before removal — place the wipers in park position, then mark the spindle flat or keyway position and the arm's angular position on the spindle with a paint pen or correction fluid; this reference mark allows the new arm to be installed at exactly the same angular position as the original, restoring the park position and sweep arc without requiring the wiper linkage to be adjusted.
  2. Remove the old arm from the spindle using a dedicated wiper arm puller — the arm's splined bore is an interference fit on the spindle taper; levering the arm with a screwdriver pried against the spindle housing cracks the housing casting and bends the spindle; a wiper arm puller applies pure axial extraction force to the arm body without any side loading on the spindle; if a puller is not available, penetrating oil applied around the spindle base and 15 minutes soak time significantly reduces the pull force required.
  3. Clean the spindle splines and taper with a wire brush before fitting the new arm — old corrosion and galling on the spindle surface prevents the new arm from seating fully to the designed engagement depth, reducing the interference fit and allowing the arm to slip angularly during operation; the spindle surface must be clean, dry, and free of grease before the new arm is pressed on — grease on the taper reduces the interference fit in the same way as corrosion.
  4. Fit the new arm at the angular position referenced by the mark made at removal and press it onto the spindle by hand until it contacts the spindle shoulder; then fit the retaining nut and torque to OEM specification — typically 14–22 Nm; undertorquing leaves the arm loose enough to slip angularly during the first heavy wiper load cycle; overtorquing may strip the nut thread or crack the arm's splined boss on pressed steel designs.
  5. Place a folded cloth on the windscreen below each arm before lowering it from the raised position — an arm lowered without a blade fitted will strike the screen with the bare metal arm tip at the full force of the new torsion spring, producing a chip or crack at the rest position; always fit a blade before lowering the arm, or protect the screen with a cloth if the blade is being fitted separately.
  6. Install the new WIPER ARM (TOYOTA/LEXUS 5344069075), fit the wiper blade, lower the arm onto the screen, activate the wipers at all speeds and confirm the blade sweeps cleanly to the designed park position, applies uniform pressure across the full arc, and does not lift from the screen or contact the A-pillar trim at the outer arc extreme before returning the vehicle to service.
Tools: wiper arm puller, wire brush for spindle cleaning, paint pen for angular position reference, torque wrench (14–22 Nm), folded cloth for screen protection during arm lowering.
Frequently Asked Questions
▲
How can wiper arm spring force be tested to confirm the arm requires replacement rather than just the blade?
The simplest comparative test is to manually lift each arm away from the screen to its fully raised position and compare the resistance between the driver and passenger arms — a fatigued spring feels significantly lighter to raise than a serviceable spring. For a quantitative measurement, a spring balance attached to the blade attachment point and pulled perpendicular to the screen surface measures the contact force directly; compare the reading against the OEM specification typically found in the vehicle service data (usually 100–200g at the blade midpoint). An arm that produces less than 70% of the OEM specified contact force will cause lifting and reduced wiping quality regardless of blade condition and should be replaced. ok.parts supplies wiper arms individually and in driver-passenger pairs at wholesale MOQ from 0.18 USD per unit.
Should both wiper arms be replaced simultaneously when only one has failed?
Replacing both arms simultaneously is recommended when one arm has failed from spring fatigue — both arms accumulate identical fatigue from the same operating environment and mileage; if one spring has weakened, the opposite is at the same fatigue stage and will produce the same lifting or contact force deficiency within a short interval. Replacing both during a single service visit ensures matched contact force on both sides of the windscreen and eliminates a repeat blade-lift complaint within a short period. When only one arm has failed from physical damage — corrosion fracture or deformation from an impact — only the damaged arm requires replacement.
How does the OEM-equivalent aftermarket unit compare to the genuine OEM part?
OEM-equivalent units in this catalogue replicate the current OEM design geometry and material specification. Quality is verified against OEM cross-reference data. When ordering in bulk, confirm with our team that the specification matches the latest OEM revision for your application.
Is white-label or custom packaging available for wholesale orders?
Yes. ok.parts works directly with the manufacturing facility and can accommodate neutral white-label packaging or fully branded packaging with your company logo, part numbers, and barcode. Minimum order quantities and lead times for custom packaging may differ from standard stock. Contact the team via the inquiry form to discuss your specific requirements.
Frequently Replaced Together
▲
PartReason for Combined Replacement
Wiper Blade
Driver and passenger — OEM length per vehicle		Wiper arm replacement provides the mandatory opportunity to fit a new blade simultaneously — a new arm with an old blade that has hardened from UV and ozone exposure will not deliver the wiping quality the new spring contact force is capable of providing. Always fit new blades when replacing arms to present the customer with a complete, fully serviceable wiper system rather than a new arm paired with a worn blade that produces the same streaking complaint on the first rain.
Wiper Motor and Linkage
OEM ref. varies by vehicle		A wiper arm that has slipped on its spindle from spline wear often indicates that the spindle nut has been loose for an extended period, during which the wiper motor has been working against the additional rotational resistance of a slipping arm. Inspect the wiper motor for abnormal current draw and the linkage pivot bearings for play while the arm is removed — a motor that has been overloaded by a slipping arm may have reduced brush life remaining and should be assessed before the new arm is installed on the same spindle.
Washer Fluid and Jet Nozzles
OEM nozzle position and jet type per vehicle		Wiper arm replacement is the recommended service time to inspect and clean the washer jet nozzles positioned on the arm body or bonnet — blocked jets reduce washer fluid delivery to the blade's contact zone, causing the blade to wipe dry glass and accelerating rubber edge wear. On vehicles with arm-mounted washer nozzles, the replacement arm includes new nozzle positions that should be confirmed correctly aimed before the first wash cycle.
